SICK CLV621 User Manual

Operating Instructions Chapter 7
CLV62x Bar Code Scanner
Startup and configuration
8011965/S345/2008-04-16 © SICK AG · Division Auto Ident · Germany · All rights reserved 59
7.3.2 Starting the SOPAS-ET configuration software and calling the scan assistant
1. Switch the power supply to the bar code scanner on.
The bar code scanner performs a self-test and is initialised.
2. Switch on the PC and start the SOPAS-ET configuration software.
The SOPAS-ET configuration software opens the program window with an English pro-
gram interface as standard.
3. In order to change the language setting, click on C
ANCEL and change the language of
the program interface to e. g. G
ERMAN/DEUTSCH via the menu TOOLS/OPTIONS.
4. Once the language setting has been changed, shut down the SOPAS-ET configuration
software and restart it.
5. In the dialog window, select the option C
REATE A NEW PROJECT and click on OK to confirm
it.
6. In the main window under S
CAN ASSISTENT click on the CONFIGURATION button.
The dialog window S
CAN WIZARD appears.
7.3.3 Configuring the Ethernet connection
TIP To establish a connection quickly and easily via Ethernet, the SOPAS-ET configuration soft-
ware has a C
ONNECTION WIZARD in the TOOLS menu.
Manual configuration:
1. In the dialog window N
ETWORK SCAN WIZARD under INTERNET PROTOCOL/INTERNET PROTOCOL
(IP), check the check box for E
NABLE IP COMMUNICATION.
2. Click on the A
DD button.
3. Enter the IP address of the bar code scanner and confirm it by pressing OK in the dialog
window.
The dialog window closes. A new entry appears in the IP A
DDRESS CONFIGURATION list.
4. Click on OK to confirm settings.
The dialog window A
DVANCED SCAN SETTINGS closes.
7.3.4 Configuring the serial connection
1. In the dialog window N
ETWORK SCAN WIZARD under SERIAL PORT/STANDARD PROTOCOL,
check the check box for E
NABLE SERIAL COMMUNICATION.
2. Click on the A
DVANCED... button.
3. Under S
ELECT BAUDRATE(S) deactivate all the baud rates except 57.6 KBD.
4. Select the following P
ORT SETTINGS: 8 data bits, no parity, 1 stop bit.
5. Click on OK to confirm settings.
The dialog window A
DVANCED SCAN SETTINGS closes.
7.3.5 Carrying out a scan
1. In the dialog window S
CAN ASSISTENT click on the NETWORK SCAN button.
2. Select the listed devices (CLV62x) and confirm via A
DD DEVICE.
Connected devices are searched for via the connection. The SOPAS-ET configuration
software inserts the found device in the project tree and uploads the current parameter
set (S
YNC CHECK).
3. For configuration of the devices see chapter 7.4.2 Configuring the bar code scanner,
page 61.
