Technical data
Tab. 10-1: Technical specifications for the CLV62x Bar Code Scanner (line/raster scanner)
Electrical connection Standard version: Cable (0.9 m (3 ft)) with 15-pole D-Sub-HD plug
Ethernet version: Revolving connector unit with two M12 circular connectors
(12-pole plug, 4-pole socket)
Operating voltage/
Current consumption
10 ... 30 V DC in accordance with IEC 364-4-41 (SELV respectively PELV acc. to IEC 60364-4-41
(2005)) / max. 4.5 W
Housing Die-cast aluminium
Reading window material Glass or plastic, see type plate CLV62x-xxxy
(y = 0: glass, y = 1: plastic)
Electrical safety according to EN 60950-1 (2006-04)
Safety class III, according to EN 61140 (2002-03)
Enclosure rating IP 65, according to EN 60529 (1991-10); A1 (2002-02)
EMC test Emission: according to EN 61000-6-3 (2001-10); immunity: according to EN 61000-6-2 (2005-08)
Vibration-/ shock-test according to EN 60068-2-6 (1995) / according to EN 60068-2-27 (1993)
Weight Standard version: 225 g with connection cable (front reading window)
Ethernet version: 205 g (7.23 oz) without connection cable (front reading window)
Ambient operating temperature/
storage temperature
0 ... +40 °C/–20 ...+70 °C
Max. rel. humidity 90%, no condensation
Housing colour SICK Blue (light blue according to RAL 5012)
1) Reading gate: code evaluation time window created internally by the reading pulse
2) Ethernet version: only switching input "Sensor 1"
Type CLV62x Bar Code Scanner
