Operating Instructions Chapter 1
CLV62x Bar Code Scanner
Notes on this document
8011965/S345/2008-04-16 © SICK AG · Division Auto Ident · Germany · All rights reserved 9
1 Notes on this document
1.1 Purpose
This document provides instructions for technical staff on the installation and operation of
the bar code scanner series CLV62x with fixed focus in the following versions:
• Line scanner / raster scanner
• Mid-range / short-range / long-range reading area
• With front / side reading window
• With cable and connector (standard version) / with connector unit (Ethernet version)
A summary of all device versions is shown in chapter 4.3 Device versions, page 24.
This document contains the following information:
• Installation
• Electrical installation
• Startup and configuration
• Maintenance
• Troubleshooting
• Replacing the bar code scanner
A step-by-step approach is taken for all tasks.
1.2 Target group
The target group of this document is persons assigned the following tasks:
Tab. 1-1: Target group
1.3 Depth of information
This document contains all the required information for installation, electrical installation
and operation of the bar code scanner at the installation location. The factory default set-
ting (basic configuration) of the bar code scanner is prepared for the use as a stand-alone
device.
Configuration of the bar code scanner for the application-specific reading conditions and
operation is carried out using the SOPAS-ET configuration software on a Windows
TM
PC. The
SOPAS-ET configuration software contains an online help system to facilitate configuration.
Important Further information about the design of the bar code scanner as well as the bar code tech-
nology is available from SICK AG, Auto Ident division.
On the Internet at www.sick.com.
Tasks Target group
Installation, electrical installation, maintenance,
replacing the device
Qualified staff, e.g. service technicians and fac-
tory electricians
Startup and configuration Trained staff, e.g. technicians or engineers
Operation of the conveyor system Qualified staff for start-up and operation of the
conveyor system
