11.4.6 Accessories: Cables for standard version
Tab. 11-7: In stock accessories: Cables and connectors for the standard version of the bar code scanner
11.4.7 Accessories: Cables for Ethernet version
Tab. 11-8: In stock accessories: Cables and connectors for the Ethernet version of the bar code scanner
Order no. Description Wires Length Connection
6034417 Extension cable for data and function interfaces,
shielded, with 15-pole D-Sub-HD socket and 15-pole, D-
Sub-HD plug
15 2 m (6.56 ft) CLV62x to CDB620, CDM420
2043413 3 m (9.84 ft)
6034418 Extension cable for data and function interfaces, Ø
7 mm (0.28 in), shielded, with 15-pole D-Sub-HD
socket and open end
15 x
0.16 mm²
(26 AWG)
2 m (6.56 ft) CLV62x for free wiring
6034419 Extension cable for data and function interfaces, Ø 6.8
mm (0.27 in), shielded, for lengths up to 3 m (9.84 ft)
16 x
0.14 mm²
(26 AWG)
Sold by the
metre
CLV62x to CDB620, CDM420
Order no. Description Wires Length Connection
6034414 Ethernet cable (patch), twisted pair, shielded, with 4-
pole M12 round plug (D coded), IP 65 and 8-pole RJ45
plug
2 x 2 2 m (6.56 ft) CLV62x to Ethernet
6029630 3 m (9.84 ft)
6034415 5 m (16.4 ft)
6030928 10 m
(32.8 ft)
6034420 Ethernet cable (patch), twisted pair, shielded, with 2 x
4-pole M12 round plug (D coded), IP 65
2 x 2 2 m (6.56 ft) CLV62x to Ethernet
6034421 3 m (9.84 ft)
6034422 5 m (16.4 ft)
2042916 Connection cable for data and function interfaces,
shielded, with 12-pole M12 round socket and 15-pole,
D-Sub-HD plug, IP 67
12 0.9 m (3 ft) CLV62x to CDB620, CDM420
2041834 2 m (6.56 ft)
2042914 3 m (9.84 ft)
2042915 5 m (16.4 ft)
6034605 Connection cable for data and function interfaces, Ø
6.2 mm (0.24 in), shielded, with 12-pole M12 round
socket and open end.
12 x
0.14 mm²
(26 AWG)
5 m (16.4 ft) CLV62x for free wiring
