Operating Instructions
Batch Scanning (Inventory Mode)
IDM corded
& IDM Bluetooth
8017159/2014-04-24
© SICK AG · Germany · All rights reserved · Subject to change without notice
23
2.7.1 Quantity feature
The scanner supports quantity feature when it enters batch scanning. When you use quantity feature, the
quantity information and scanned barcode data will be stored into the memory storage together. You can
enter the quantity information from 1 to 9999 by scanning the following quantity commands right after you
scanned the barcode data.
Quantity 0
Quantity 5
Quantity 3
Quantity 8
Quantity 1
Quantity 6
Quantity 4
Quantity 9
Quantity 2
Quantity 7
2.7.2 Data output format
There are three ways to output the stored barcode data and quantity information. The preset output format is
to transmit stored data as many times as the quantity indicates. But you still can set the scanner to output
stored barcode data together with quantity information in two fields, and a preset delimiter (“,”) will be output
in between. To fulfill different application requirements, both the delimiter and the output sequence can be
changed.
As many times as the quantity indicates

<Field delimiter><Quantity><Scanned data>
<Scanned data><Field delimiter><Quantity>
