Symbology Reading Control
Operating Instructions
IDM corded & IDM Bluetooth
© SICK AG · Germany · All rights reserved · Subject to change without notice
UPC/EAN Security Level
The scanner offers three levels of decode security for UPC/EAN bar codes:
• Level 0: If you are experiencing misread of poorly-printed or out-of-spec. bar codes, especially in
characters 1, 2, 7, and 8 in level 1, please select level 0. Selection of this security level may
significantly impair the decoding ability of the scanner.
• Level 1: This is the default setting which allows the scanner to operate fastest, while providing
sufficient security in decoding “in-spec” UPC/EAN bar codes.
• Level 2: If you are experiencing misread of poorly-printed, soiled or damage bar codes in level 1,
please select level 2. This is the most aggressive setting and may increase the misread.
3.7.9 UCC Coupon Extended Code
Family Code Selection P.C. Parameter Selection Option Code
UCC Coupon Extended
Code Setting
SS Disable UCC Coupon Extended Code 0
SS Enable UCC Coupon Extended Code
1
UCC Coupon Extended Code
When UCC coupon extended code function is enabled, scanner decodes UPC-A barcodes starting with digit
“5”, EAN-13 barcodes starting with digit “99” and GS1-128 Coupon Codes. UPC-A, EAN-13 and EAN-128 must
be enabled to scan all types of Coupon Codes.
