SICK IDM1 Series User Manual

Operating Instructions
Keyboard Interface Control
IDM corded
& IDM Bluetooth
8017159/2014-04-24
© SICK AG · Germany · All rights reserved · Subject to change without notice
35
3.4.4 Function Key & Key Pad Emulation, Upper/Lower Case
PROGRAM
F_DEFAULT
Family Code Selection P.C. Parameter Selection Option Code
Function Key Emulation
SS Enable ASCII 00-31 code as keyboard function code
output 
0
SS Ctrl-Output 1
Refer to Appendix – Keyboard Function Code Table for details.
Key Pad Emulation
SS Disable key pad emulation  0
SS Enable numeric output as key pad (Num Lock On)
output
1
Upper/ Lower Case
SS
Normal case (neglect the upper/lower case control)  0
SS Inverse case (change all characters output to inverse
case)
1
SS Upper case (force all characters output as upper case) 2
SS Lower case (force all characters output as lower case) 3
