SICK IDM1 Series User Manual

Operating Instructions
Host Interface Selection
IDM corded
& IDM Bluetooth
8017159/2014-04-24
© SICK AG · Germany · All rights reserved · Subject to change without notice
31
3.3 Host Interface Selection
PROGRAM
F_DEFAULT
Family Code Selection P.C. Parameter Selection Option Code
Host Interface Selection
MS IBM PS/2 25-30 series keyboard wedge interface 02
MS Standard/TTL RS-232 peer-to-peer serial 06
MS Wand Emulation 08
MS USB Com Port Emulation 09
MS PS/2 (DOS/V) direct link (keyboard replacement) 10
MS PS/2 (DOS/V) keyboard wedge turbo mode 13
MS PS/2 (DOS/V) keyboard wedge standard mode 14
MS Laser emulation 17
MS USB HID standard mode  18
MS USB HID turbo mode 19
MS USB HID Legacy 20
IDM2xx series doesn’t support Wand emulation, Laser emulation and USB HID Legacy
