3.12.6 Select Barcode Symbology
You can select one or all types of barcode symbologies to use Condensed DataWizard for advanced
transmission arrangement. If you scan “00” to select all types, the Hand-held scanner will arrange all
incoming data to meet your pre-defined format. If you want to select only one type of barcode, please select
one of the option codes listed below.
1D Barcode Symbology
Code 128 01 EAN-8 with 5 supplement 45 UK/ Plessey 12
GS1-128 31 Codabar/ NW-7 06 Telepen 13
UPC-A 02 Code 39 07 GS1 DataBar 14
UPC-A with 2 supplement 32 Code 32 37 IATA 15
UPC-A with 5 supplement 42 Trioptic Code 39 47 Coupon Code 16
UPC-E 03 Matrix 2 of 5 38 PDF417/ Micro PDF417 17
UPC-E with 2 supplement 33 Interleaved 2 of 5 48 Codablock F 18
UPC-E with 5 supplement 43 China Postal Code 58 Code 16K 19
EAN-13 04 German Postal Code 68 Code 49 20
EAN-13 with 2 supplement 34 Standard/ Industrial 2 of 5 08 GS1 DataBar Limited 22
EAN-13 with 5 supplement 44 Code 93 09 GS1 DataBar Expanded 23
EAN-8 05 Code 11 10 Composite Codes 24
EAN-8 with 2 supplement 35 MSI/ Plessey 11 Micro PDF417 25
2D Barcode Symbology
QR Code A0 Maxi Code A2 GS1 Data Matrix A5
Micro QR Code A0 Aztec Code A3
Data Matrix A1 Chinese Sensible Code A4
Postal Codes
Korea Post Code 21 Intelligent Mail barcode B3 Planet Post B6
Australian Post B0 Japanese Post B4 Postnet B8
British Post B1 KIX Post B5
