3 Product description
3.1 Product variants
Flex product variant
The Flex product variant is a camera housing with a C-mount thread. The product
can be assembled from individual components to suit the particular application. The
individual components can be ordered separately as accessories. Only certain lenses
and illumination units are compatible depending on the product type. Use only products
from SICK.
3.2 Scope of delivery
No. of
units
Component Note
1 Device in the version ordered
•
Camera housing with C-mount threaded connec‐
tion
•
Order individual components separately as
accessories and mount them independently.
•
Light inlet is sealed with a protective cap.
•
Electrical connections are sealed with protective
caps.
•
Without holders and connecting cables
2 Sliding nut, 5.5mm deep, M5
threaded mounting hole
•
Alternative mounting option for the device
instead of the threaded mounting hole
•
Use in pairs.
1 Hexagon key WAF2 For mounting the VI83I illumination unit
1 Printed safety notes, multilin‐
gual
Brief information and general safety notes
The actual scope of delivery may differ for special designs, additional orders or due to
the latest technical changes.
3.3 Type label
The type label contains information for identifying the product.
3 PRODUCT DESCRIPTION
12
O P E R A T I N G I N S T R U C T I O N S | Lector85x 8027859/1INN/2023-03-08 | SICK
Subject to change without notice
