SICK Lector85x User Manual

11 Technical data
NOTE
The relevant online product page for your product, including technical data, dimensional
drawing, and connection diagrams, can be downloaded, saved, and printed from the
Internet.
The call is made via the SICK Product ID: pid.sick.com/{P/N}/{S/N}
{P/N} corresponds to the part number of the product, see type label.
{S/N} corresponds to the serial number of the product, see type label (if indicated).
Please note: This documentation may contain further technical data.
11.1 Features
Typical applica‐
tion
Indoor area
Variant Base device
Optical focus Adjustable focus
Manual sharpness and aperture setting on optional lens
Sensor CMOS matrix sensor, grayscale values
Sensor resolution V2D8505x–xxxxxxxxxx: 5megapixel (2,464px x 2,048px)
V2D8509x–xxxxxxxxxx: 9megapixel (4,096px x 2,176px)
V2D8512x–xxxxxxxxxx: 12megapixel (4,096px x 3,008px)
Integrated illumi‐
nation unit
Order separately as an accessory
For example variant with VI83I illumination unit:
•
Type “visible white light medium and feedback LED” (part number:
2125084)
•
Type “visible white light wide and feedback LED” (part number:
2125085)
32 LEDs: visible white light (T = 6,500K ±1,000K)
LED risk group of
integrated illumi‐
nation unit
Risk group 1 (low risk) according to IEC62471-1: 2006-07/EN62471-1:
2008-09
Radiance:
•
L
B

1)
: <10 x 10
3
W/(m
2
sr) within 100seconds (RG 1); at a distance
≥200mm
•
L
R

2)
: <6 x 10
5
W/(m
2
sr) within 10seconds (RG1); at a distance
≥200mm
Feedback LED
3)
Optional e.g., variant of the VI83I illumination unit
2 LEDs:
•
Visible green light (λ = 525nm ±15nm)
•
Visible red light (λ = 645nm ±15nm)
LED risk group of
feedback LED
Risk group 1 (low risk) according to IEC62471-1: 2006-07/EN62471-1:
2008-09
Laser alignment
aid
3)
1 laser, can be switched off
Visible red light (λ = 630nm ... 680nm)
Laser class Laser alignment aid:
Class 1 Laser Product according to EN/IEC 60825-1: 2014. Complies with
21CFR1040.10/11 except for conformance with IEC60825-1 Ed.3., as
described in Laser Notice No.56 dated 8May2019.
P <1.40mW
TECHNICAL DATA 11
8027859/1INN/2023-03-08 | SICK O P E R A T I N G I N S T R U C T I O N S | Lector85x
41
Subject to change without notice
