Dimensions (L x
W x H)
143.4mm x 90mm x 46mm
5)
1)
The serial interface and the digital inputs and outputs are not available.
2)
Maximum length of cable: 10m
3)
For digital outputs without load.
4)
Outputs are not available.
5)
When the cover is open, the device no longer conforms with the specified protection class. Protect the
device against moisture and dust when the cover is open temporarily.
6)
Prerequisites:
•
The optics protection hood must be screwed tightly onto the device.
•
The cover on the top of the device is closed.
•
The cables plugged into the electrical connections must be screwed tight. Electrical connections
that are not being used are sealed off with a protective cap.
7)
Only housing. Without lens, optics protection hood, plug connector and protective caps.
11.3 Dimensional drawing
P2
P1
P3
X2
X1
P2
P1
P3
X2
X1
P2
P1
P3
X2
X1
1
2
3
Lector 85x
40.3
(1.59)
0.9
(0.04)
46
(1.81)
90
(3.54)
21.4
(0.84)
75.6
(2.98)
7.2
(0.28)
102
(4.02)
22.2
(0.87)
13.6
(0.54)
97.8
(3.85)
15.9
(0.55)
143.4
(5.65)
min. 8 (0.31) - max. 87 (3.43)
Figure 12: Structure and device dimensions, unit: mm (inch), decimal separator: period
1
4 tapped blind holes, M2.5, 5.5mm deep, for mounting the spacer
2
2 M5 sliding nuts; 5.5mm deep; pivoting; as an alternative method of mounting the
device
3
4 M5 tapped blind holes, 5.5mm deep; for mounting the device
11.4 Performance
Readable code
structures
1D codes, Stacked, 2D codes
1D code types
(bar code types)
GS1-128 / EAN 128, UPC/GTIN/EAN, 2/5 Interleaved, GS1 DataBar, Code
39, Code 128, Codabar, Code 32, Code 93
2D code types Data-Matrix ECC200, MaxiCode, QR code
Stacked code
types
PDF417
Code qualifica‐
tion
On the basis of ISO/IEC16022, ISO/IEC15415, ISO/IEC18004
TECHNICAL DATA 11
8027859/1INN/2023-03-08 | SICK O P E R A T I N G I N S T R U C T I O N S | Lector85x
43
Subject to change without notice
