Internal image
memory
Not available
11.5 Interfaces
Communication
interfaces
•
Ethernet 1/2
•
Ethernet 3
•
Ethernet via USB (RNDIS)
1)
•
CAN 1 (male connector, M12, 17-pin, A-coded)
•
LA version: CAN 2 (male connector, M12, 5-pin, A-coded)
•
Serial interface 1
•
Serial interface 2
Ethernet Protocol: TCP/IP
Function:
•
Host (data output of the read result)
•
AUX (Service)
1)
•
FTP (image transfer)
Data transmission rate: 10/100/1,000Mbit/s
MAC address (device-specific), see type label
CAN Protocol: SICK CAN sensor network CSN (secondary)
Function: Host (data output of the read result)
Data transmission rate: 500kbit/s
USB 2.0 Ethernet via USB (RNDIS)
1)
3)
Reading pulse CAN
Optical displays 10 status LEDs
2 feedback LEDs of the integrated VI83I illumination unit (green, red)
Operator interfa‐
ces
Web server
Configuration
software (param‐
eterization)
SOPASair
microSD memory
card
Functions:
•
Cloning
Data storage and
retrieval
Image and data storage via external FTP
External illumina‐
tion control
Not available
1)
For temporary use as a service interface only.
2)
For example: configuration, diagnosis, transponder access or display of the read result.
3)
If the cover is open, the device does not fulfill any specified enclosure rating. Only briefly open the cover.
Protect the device against moisture and dust during this time.
4)
Memory card is available as an optional accessory. To ensure that the memory card functions reliably,
only use card types (industrial standard) approved by SICK. Other functions are available upon request.
11.6 Ambient data
Electromagnetic
compatibility
(EMC)
Immunity: IEC61000-6-2:2016, ENIEC61000-6-2:2019
Emission: IEC61000-6-4:2018, ENIEC61000-6-4:2019
Vibration resist‐
ance
EN60068-2-6:2007, EN60068-2-64:2019
Shock resistance EN60068-2-27:2008
11 TECHNICAL DATA
44
O P E R A T I N G I N S T R U C T I O N S | Lector85x 8027859/1INN/2023-03-08 | SICK
Subject to change without notice
