SICK Lector85x User Manual

Scanning fre‐
quency
30Hz, at 5megapixels resolution
20Hz, at 9megapixels resolution
15Hz, at 12megapixels resolution
Code resolution ≥0.1mm (depending on the lens)
Working range 500mm…2,500mm
Depends on the lens
Lens C-mount
Order separately as an accessory
Optical format:
V2D8505x–xxxxxxxxxx: 1/1.8"
V2D8509x–xxxxxxxxxx: 1/1.1"
V2D8512x–xxxxxxxxxx: 1/1.1"
1)
L
B
= Hazard from blue light.
2)
L
R
= Hazard to the retina of the eye due to heating.
3)
Not available.
11.2 Mechanics and electronics
Connection type
•
1 male connector, M12, 17-pin, A-coded (power, CAN, serial interface,
I/O)
1)

2)
•
1 male connector, M12, 5-pin, A-coded (Power, CAN)
•
3 female connectors, M12, 8-pin, X-coded (GB Ethernet)
Supply voltage V
S
DC 24V ±20%
Voltage source in accordance with ES1 (EN62368-1) or SELV (EN60950-1)
Power consump‐
tion
Operation: 24W ±20% typical
2)
Current con‐
sumption
Max. 2.0A
Output current Sum of output currents: max. 400mA
4)
Housingmaterial Aluminum die cast
Housing color Anthracite gray (RAL7016)
Viewing window
material
Glass (PMMA), 2mm thick, anti-reflection coating, scratch-proof coating
Cover (top of
device)
Material: rubber
Function
•
Inserting or removing the optional memory card
•
Temporary use of the USB interface as a service interface
Function: For temporary access to the microSD memory card slot and the
USB connection
Foldable
5)
Enclosure rating IP 65 (IEC60529:2013 +C1:2013 +C2:2015 +AMD2 C1:2019,
EN60529:1991 +A1:2010 +A2:2013 +AC:2019-02)
4)
Electrical safety EN 61010-1:2010
EN 61010-1:2010/A1:2019
EN 61010-1:2010/A1:2019/AC:2019-04
Weight Max. 640g, without lens and connecting cables
11 TECHNICAL DATA
42
O P E R A T I N G I N S T R U C T I O N S | Lector85x 8027859/1INN/2023-03-08 | SICK
Subject to change without notice
