SICK WT24-2 Series User Manual

WT24-2Bx4x
/ -2Bx5x /
-2Vx4x /
-2Vx5x
-2Rx4x /
-2Rx5x
-2Bx1x /
-2Vx1x /
-2Bx2x /
-2Vx2x
-2Rx1x /
-2Rx2x
Output current I
max.
100 mA 100 mA
Switching current (switching voltage)
I
max.
4A@250V
AC, 4A@24V
DC,
0.125A@25
0 V DC
3)
4A@250V
AC, 4A@24V
DC,
0.125A@25
0 V DC
3)
Switching frequency 1000 Hz
4)
10 Hz
4)
1000 Hz
4)
10 Hz
4)
Max. response time ≤ 500 µs
5)
≤ 10 ms
5)
≤ 500 µs
5)
≤ 10 ms
5)
Enclosure rating
6)
-2B2x0,
-2B3x3,
-2V2x0: IP67
-2B4x0,
-2V5x0:
IP69
7)
-2R2x0,
-2R5x8,
-2R5x9:
IP67
-2B2x0,
-2B3x3,
-2V2x0: IP67
-2B4x0,
-2V5x0:
IP69
7)
-2R2x0,
-2R5x8,
-2R5x9:
IP67
Protection class II
8)
II
8)
II
8)
II
8)
Circuit protection A, B, C
9)
A, C
9)
A, B, C
9)
A, C
9)
Ambient operating temperature –40 °C ...
+60 °C
–40 °C ...
+60 °C
–40 °C ...
+60 °C
–40 °C ...
+60 °C
1)
Object with 90 % remission (based on standard white DIN 5033)
2)
Limit values; terminal connection: permissible wire cross-sections 0.14 to 1.5 mm
2
; male connector:
≤ 4 A
3)
Usage category: AC-15, DC-13 (EN 60947-1)
4)
With light / dark ratio 1:1
5)
Signal transit time with resistive load
6)
Pursuant to EN 60529
7)
Replaces IP69 K pursuant to ISO 20653: 2013-03
8)
Rated insulation voltage U
i
250 V, overvoltage category II
9)
A = U
B
-Anschlüsse verpolsicher
B = Ein- und Ausgänge verpolsicher
C = Störimpulsunterdrückung
TECHNICAL DATA 13
8008784.14BT | SICK
Subject to change without notice
