Example:
Pretest (V) and high-voltage test (H) were successfully completed;
thermal test (W) is not required; final tests (E) still need to be carried
out.
5.3 SD4B Type Designation
Type: e.g. 0SD4BB1D1P000U
Version: e.g. 1.000
0SD4 B b k X Y Z f p s z a b c d
Generation
0SD4
Product series [A-Z]
B = basic/board
b: size [width × height × depth]
B = 25 × 165 × 120 mm
k: type of cooling [0-9]
1 = passive air cooling
X: current class [A-Z] [Arms]
D = 14
Y: number of output stages or current class of dou-
ble-axis device [1-4, A-Z]
1 = single output stage
Z: voltage class (input voltage [Vac=A-M, Vdc=N-Z] /
output voltage [Vac])
A = input 80 Vac / output 50 Vac
f: variant fieldbus [0-9]
0 = no fieldbus
1 = EtherCAT / POWERLINK / PROFINET RT
p: extension module (no retrofit) [0-9]
0 = no extension module
s: safety option (STO is always available) [0-9]
0 = no additional safety functions
1 = SFM/SLOF
z: export license [A-Z]
U = unlimited output frequency
L = max. output frequency limited to 599 Hz
abcd: administrative options [0-9, A-Z]
Device version X.XXX
Continuous counter: If there is no device version, 0.000 is indicated here. If a device
is exchanged by a device of another version, please contact SIEB & MEYER to check
whether the devices are compatible or not.
In addition, the device version indicates the update capability of the internal device soft-
ware, e.g. BIOS, FPGA or Firmware.
5.4 General Technical Data
The following data apply to all devices of the series SD4B.
