SIEB & MEYER SD4B User Manual

Connectors
7.6 X11 – Ethernet 10/100 Mbit
Ethernet interface for the communication with the connected PC for parameterization
and initial operation (Modbus TCP protocol)
8-pole female RJ45 connector, shielded, Ethernet connection for standard patch ca-
bles
X11
Pin /
LED
I/O Name / Status Meaning
Green
No data exchange
LED 0 O
Flickers green
Data exchange (TX/RX) active
8
7
I/O VC− PoE (NC)
6 I RX− Receive data −
5
4
I/O VC+ PoE (NC)
3 I RX+ Receive data +
2 O TX− Transmit data −
1 O TX+ Transmit data +
0
1
8
1
LED 1 O
Yellow
Ethernet connection established
7.6.1 Ethernet communication
The drive communicates with the software drivemaster4 via the Ethernet interface . By
means of the software drivemaster4, the SD4x drives are parameterized, put into op-
eration and maintained.
Fig. 20: Ethernet communication (X11)
Drive n
Maintenance
...
Machine hall
supervisor
...
SWITCH
Drive 1
RJ45 patch cable
100 MBit
IT infrastructure
(corporate LAN)
WWW
drivemaster4
drivemaster4
Fernwartung
Service
drivemaster4
Drive 2
Fig. 20: Ethernet communication (X11)
40 Drive Amplifier SD4B - Hardware Description
