Value applies when mounted to cooling surface of the installation; minimum size of cooling surface: 6 dm² (natural convec-
tion).
(3)
Applies to device variant 0SD4BB1D1PxxxL (only (with limited output frequency), not for device variant 0SD4BB1D1PxxxU
(with unlimited output frequency).
Tab. 7: Electrical data 0SD4BB1D1Pxxxx
6.2.2 Overload Times
Load cutoff:
Fig. 7: Load cutoff 0SD4BB1D1Pxxxx
Fig. 7: Load cutoff 0SD4BB1D1Pxxxx
Overload cutoff:
Fig. 8: Overload cutoff 0SD4BB1D1Pxxxx
Fig. 8: Overload cutoff 0SD4BB1D1Pxxxx
27Drive Amplifier SD4B - Hardware Description
0SD4BB1D1Pxxxx
