Message Description
MSG_SB38_FEEDBACK0_NOK Feedback 0 is not OK
MSG_SB39_FEEDBACK1_NOK Feedback 1 is not OK
MSG_SB40_INV_TARGET_SPEED Inversion of reference value is active
MSG_SB41_SKIP_ACTIVE Skip bandwidth is active
MSG_SB42_JOG1_ACTIVE Jog speed 1 is active
MSG_SB43_JOG2_ACTIVE Jog speed 2 is active
MSG_SB44_DIN_REDUCED_TORQUE_LIMIT Torque reduction via digital input is active
MSG_SB45_WARN_POWERSTAGE_I2T_OVERLOA
D
Power output stage - Warning I²t load
MSG_SB46_DIN_HALT Reserved
MSG_SB47_DIN_HW_ENABLE_MISSING “Switch on” via fieldbus is available but hardware enable is not
Tab. 10: Messages of SD4x series
Tab. 10: Messages of SD4x series
63Drive Amplifier SD4B - Hardware Description
SD4x Drive Messages
