Siemens 3RS2

Process data and data sets
16
16.1 Data sets - structure
Table 16-1 Device-independent data sets
Data set Name Access
(r = readable,
w = writable)
Value Length
(bytes)
Address
(dec)
Subindex
supported
0x00 (0) Yes Parameter Page 0 r — 16
0x10 (16) No Vendor Name r SIEMENS AG 11
0x11 (17) No Vendor Text r Vendor text (http://
support.automation.siemens.com/WW/
view/en/29801139/130000)
max. 64
0x12 (18) No Product Name r Device name
1)
(e.g. SIRIUS Line Monitor‐
ing Relay for IO-Link)
max. 64
0x13 (19) No Product ID r Article number
1)
(e.g. 3RS2800-1BA40) 14
0x17 (23) No Firmware Revision r Firmware version
1)
7
0x18 (24) No Application Speci󹪝c Tag r / w — max. 32
1) This value is di󹪜erent for each device
16.2 Data sets - Overview
• Process image output (PIQ) and input (PII) (Page 102)
• Identi󹪝cation data (Page 103)
• Data set 92 - Diagnostics (Page 104)
• Data set 94 - measured values (Page 106)
• Data set 95 - measured values (󹪞oating-point format) (Page 107)
• Data set 131 - parameters (Page 107)
3RS2 temperature monitoring relay
Equipment Manual, 02/2022, A5E42462552002A/RS-AB/002 101
