• KTY84 (monitoring for overshoot/undershoot)
• NTC
1)
(monitoring for overshoot)
1) NTC type: B57227-K333-A1 (100 °C: 1.8 kΩ; 25 °C: 32.762 kΩ)
For more detailed information, refer to Chapter Resistance sensors (Page 69).
Note
Using the current input 4 ... 20 mA
If you use the 4 ... 20 mA current input (selectable via the operating menu), all other sensor
inputs are inactive.
7.5 Operator control
7.5.1 LEDs
The following LEDs are mounted on the front of the sensor expansion modules:
Sensor expansion module
7.5 Operator control
3RS2 temperature monitoring relay
64 Equipment Manual, 02/2022, A5E42462552002A/RS-AB/002
