DI (4 bytes) PII
DI1.7 ---
DI2.0 - DI3.7 Analog value
1)
1) The analog value is a 16-bit integer value. The complete measured value is produced together with the
analog value coding (DI1.0 - DI1.4), which de󹪝nes the unit and resolution of the analog value.
16.4 Identi󹪝cation data
Identi󹪝cation data refers to data stored in a module that supports you in the following areas:
• When checking the system con󹪝guration
• When locating modi󹪝ed system hardware
• When troubleshooting a system.
Modules can be uniquely identi󹪝ed using the identi󹪝cation data.
Table 16-4 Identi󹪝cation data
DPP
1)
Data set Access Parameter Lengt
h
(bytes
)
Default setting
Index (dec) Index (dec)
0x07 (7) — r Vendor ID 2 0x00
0x08 (8) — r 0x2A
0x09 (9) — r Device ID 3 0x09
0x0A (10) — r 0x07
0x0B (11) — r 0x30
— 0x10 (16) r Vendor Name 11 SIEMENS AG
— 0x11 (17) r Vendor Text max. 6
4
Vendor text (http://
support.automation.siemens.com/WW/
view/en/29801139/130000)
— 0x12 (18) r Product Name max.
64
SIRIUS temperature monitoring relays 3RS2800
— 0x13 (19) r Product ID 14 3RS2800-.BA40
— 0x17 (23) r Firmware Revision 7 Firmware Version
2)
— 0x18 (24) r / rw Application Speci󹪝c Tag 32
max.
—
1) Direct Parameter Page
2) Value varies for each temperature monitoring relay
Process data and data sets
16.4 Identi󹪝cation data
3RS2 temperature monitoring relay
Equipment Manual, 02/2022, A5E42462552002A/RS-AB/002 103
