Siemens 3RS2

Technical data
13
13.1 Technical data in Siemens Industry Online Support
Technical data sheet
You can also 󹪝nd the technical data of the product at Siemens Industry Online Support (
https://
support.industry.siemens.com/cs/ww/en/ps/).
1. Enter the full article number of the desired device in the "Product" 󹪝eld, and con󹪝rm with the
Enter key.
2. Click the "Technical data" link.
13.2 Insulation concept of the plant
WARNING
Design of the isolation concept
When designing the insulation concept, note the dielectric properties of the devices.
See the following circuit diagrams.
=: Reinforced insulation (3RS2800)
-: Basic insulation (all variants)
3RS2 temperature monitoring relay
