Step Instructions Figure
1 Insert the detachable terminals into
the guide rail of the device.
2 Slide the detachable terminals back
until they audibly engage.
11.12 Removing the terminals
WARNING
Hazardous voltage
Can cause death, serious injury, or property damage.
Turn o and lock out all power supplying this device before working on this device.
Removing the terminals
Note
Screw terminals/push-in terminals
Screw and push-in terminals are removed from the module on the same principle.
Connection
11.12 Removing the terminals
3RS2 temperature monitoring relay
84 Equipment Manual, 02/2022, A5E42462552002A/RS-AB/002
