Siemens 3RS2

CAx data
14
14.1 CAx data types
You can choose from the following information for products:
• Reduced 3D model
• 2D dimension drawing
• 3D rendering
• Connection diagram
• Wiring diagram
• EPLAN macro 󹪝les
• Pro Panel macro 󹪝les
• AutoCAD electrical data
• GSP in ANSI
• ecl@ss functional structure
14.2 CAx data
You can 󹪝nd the CAx data in the Siemens Industry Online Support (
https://
support.industry.siemens.com/cs/ww/en/ps/).
1. Enter the full article number of the desired device in the "Product" 󹪝eld, and con󹪝rm with the
Enter key.
2. Click the "CAx data link.
3RS2 temperature monitoring relay
Equipment Manual, 02/2022, A5E42462552002A/RS-AB/002 97
