Byte.Bit Description
40.2 Reserved
40.3 Reserved
41.0 Current input - Measured value is above the two limit values (monitoring for overshoot)
41.1 Current input - Measured value is above the rst limit value (monitoring for overshoot)
41.2 Current input - Measured value is within range of limit values
41.3 Current input - Measured value is below the rst limit value for overshoot (monitoring for undershoot)
41.4 Current input - Measured value is below the two limit values (monitoring for undershoot)
42.0 Current input - Measured value is above the two warning limits (monitoring for overshoot)
42.1 Current input - Measured value is above the rst warning limit (monitoring for overshoot)
42.2 Current input - Measured value is within range of limit values
42.3 Current input - Measured value is below the rst warning limit for overshoot (monitoring for undershoot)
42.4 Current input - Measured value is below the two warning limits (monitoring for undershoot)
16.6 Data set 94 - measured values
Note
Bits that are not described in the tables below are reserved and should be ignored.
Note
Sub-indices are not supported.
Table 16-6 Data set 94 - measured values
Byte.Bit Description
Temperature monitoring
16.0 … 17.7 Temperature in °C (temperature sensor 1)
18.0 … 19.7 Temperature in °F (temperature sensor 1)
20.0 ... 21.7 Temperature in °C (temperature sensor 2)
22.0 ... 23.7 Temperature in °F (temperature sensor 2)
24.0 ... 25.7 Temperature in °C (temperature sensor 3)
26.0 … 27.7 Temperature in °F (temperature sensor 3)
28.0 … 29.7 Temperature T
min
in °C
30.0 … 31.7 Temperature T
min
in °F
32.0 … 33.7 Temperature T
max
in °C
34.0 … 35.7 Temperature T
max
in °F
36.0 … 37.7 Temperature T
avg
in °C
38.0 … 39.7 Temperature T
avg
in °F
40.0 ... 41.7 Current input
Process data and data sets
16.6 Data set 94 - measured values
3RS2 temperature monitoring relay
106 Equipment Manual, 02/2022, A5E42462552002A/RS-AB/002
