Byte.Bit Description
30.0 Temperature sensor 1 - Measured value is above the two warning limits (monitoring for overshoot)
30.1 Temperature sensor 1 - Measured value is above the 󹪝rst warning limit (monitoring for overshoot)
30.2 Temperature sensor 1 - Measured value is within range of warning limits
30.3 Temperature sensor 1 - Measured value is below the 󹪝rst warning limit for overshoot (monitoring for un‐
dershoot)
30.4 Temperature sensor 1 - Measured value is below the two warning limits (monitoring for undershoot)
Temperature sensor 2
32.0 Temperature sensor 2 - Measuring range overshoot
32.1 Temperature sensor 2 - Wire break
32.2 Temperature sensor 2 - Short-circuit
32.3 Reserved
33.0 Temperature sensor 2 - Measured value is above the two limit values (monitoring for overshoot)
33.1 Temperature sensor 2 - Measured value is above the 󹪝rst limit value (monitoring for overshoot)
33.2 Temperature sensor 2 - Measured value is within range of limit values
33.3 Temperature sensor 2 - Measured value is below the 󹪝rst limit value for overshoot (monitoring for under‐
shoot)
33.4 Temperature sensor 2 - Measured value is below the two limit values (monitoring for undershoot)
34.0 Temperature sensor 2 - Measured value is above the two warning limits (monitoring for overshoot)
34.1 Temperature sensor 2 - Measured value is above the 󹪝rst warning limit (monitoring for overshoot)
34.2 Temperature sensor 2 - Measured value is within range of warning limits
34.3 Temperature sensor 2 - Measured value is below the 󹪝rst warning limit for overshoot (monitoring for un‐
dershoot)
34.4 Temperature sensor 2 - Measured value is below the two warning limits (monitoring for undershoot)
Temperature sensor 3
36.0 Temperature sensor 3 - Measuring range overshoot
36.1 Temperature sensor 3 - Wire break
36.2 Temperature sensor 3 - Short-circuit
36.3 Reserved
37.0 Temperature sensor 3 - Measured value is above the two limit values (monitoring for overshoot)
37.1 Temperature sensor 3 - Measured value is above the 󹪝rst limit value (monitoring for overshoot)
37.2 Temperature sensor 3 - Measured value is within range of limit values
37.3 Temperature sensor 3 - Measured value is below the 󹪝rst limit value for overshoot (monitoring for under‐
shoot)
37.4 Temperature sensor 3 - Measured value is below the two limit values (monitoring for undershoot)
38.0 Temperature sensor 3 - Measured value is above the two warning limits (monitoring for overshoot)
38.1 Temperature sensor 3 - Measured value is above the 󹪝rst warning limit (monitoring for overshoot)
38.2 Temperature sensor 3 - Measured value is within range of warning limits
38.3 Temperature sensor 3 - Measured value is below the 󹪝rst warning limit for overshoot (monitoring for un‐
dershoot)
38.4 Temperature sensor 3 - Measured value is below the two warning limits (monitoring for undershoot)
Current input 4 ... 20 mA
40.0 Current input - measuring range overstepping
40.1 Reserved
Process data and data sets
16.5 Data set 92 - Diagnostics
