16.7 Data set 95 - measured values (󹪞oating-point format)
Table 16-7 Data set 95 - measured values (󹪞oating-point format)
Byte.Bit Description
Temperature monitoring
16.0 … 19.7 Temperature in °C (temperature sensor 1)
20.0 … 23.7 Temperature in °F (temperature sensor 1)
24.0 ... 27.7 Temperature in °C (temperature sensor 2)
28.0 ... 31.7 Temperature in °F (temperature sensor 2)
32.0 ... 35.7 Temperature in °C (temperature sensor 3)
36.0 … 39.7 Temperature in °F (temperature sensor 3)
40.0 … 43.7 Temperature T
min
in °C
44.0 … 47.7 Temperature T
min
in °F
48.0 … 51.7 Temperature T
max
in °C
52.0 … 55.7 Temperature T
max
in °F
56.0 … 59.7 Temperature T
avg
in °C
60.0 … 63.7 Temperature T
avg
in °F
64.0 ... 47.7 Current input
16.8 Data set 131 - parameters
Note
Bits that are not described in the tables below are reserved and should be ignored.
Note
Sub-indices are not supported.
Table 16-8 Data set 131 - parameters
Byte.Bit Description
Operating system functions
16.0 Group diagnostics
Default: [1]
[0] disabled
[1] enabled
16.1 Group error diagnostics
Default: [1]
[0] disabled
[1] enabled
16.2 Reserved
Process data and data sets
16.8 Data set 131 - parameters
3RS2 temperature monitoring relay
Equipment Manual, 02/2022, A5E42462552002A/RS-AB/002 107
