Siemens 3RS2

Byte.Bit Description
16.3 Reserved
16.4 Local limit change
Default: [1]
[0] disabled
[1] enabled
16.5 Local parameter change
Default: [1]
[0] disabled
[1] enabled
16.6 Local reset
Default: [1]
[0] disabled
[1] enabled
16.7 Retentive error memory
Default: [1]
[0] disabled
[1] enabled
17.0 ... 17.7 Analog value coding
Type: BYTE
Default: 5
Min: 1
Max: 160
Temperature monitoring
24.0 Reset
Default: [0]
[0] manual
[1] auto
24.1 Reserved
24.2 ... 24.4 Monitoring mode
Default: [0]
[0] Overshoot
[1] Undershoot
[2] Window monitoring
24.5 ... 24.7 Temperature unit
Default: [0]
[0] °C (degrees Celsius)
[1] °F (degrees Fahrenheit)
[2] mA
[3] %
25.0 ON-delay time (at Power ON)
Default: [0]
[0] disabled
[1] enabled
Process data and data sets
16.8 Data set 131 - parameters
3RS2 temperature monitoring relay
108 Equipment Manual, 02/2022, A5E42462552002A/RS-AB/002
