Connection
11
11.1 Warning notices
WARNING
Hazardous voltage
Causes electric shock and burns when touched.
Turn o and lock out all power supplying the system and device before working on the device.
Note
The following gures are schematic representations
The gures below show a 22.5 mm enclosure. The overall width, overall depth, terminals (type
and number of terminals) and accessories and mounted components are similar and may dier
from the actual product.
11.2 General information
Special feature of the spring-type terminal:
Spring-type terminals are used for fast, vibration-proof wiring without the need for tools and
with cable routing and terminal operation from the same direction.
Replacement of terminals:
Individual terminals can be replaced not only in the case of screw-type connections, but also in
the case of spring-type connections (with push-in function). This process minimizes the wiring
overhead – only the individual terminal concerned needs to be rewired, not the entire device.
3RS2 temperature monitoring relay
Equipment Manual, 02/2022, A5E42462552002A/RS-AB/002 75
