16.5 Data set 92 - Diagnostics
Note
Bits that are not described in the tables below are reserved and should be ignored.
Note
Sub-indices are not supported.
Table 16-5 Data set 92 - Diagnostics
Byte.Bit Description
Operating system functions 3RS2
16.0 Ready
16.1 Group error
16.2 Group warning
16.3 Reserved
16.4 Sensor expansion module - communication error
16.5 Parameter assignment active
16.6 Invalid parameter
16.7 Self-test error / internal error
17.0 Parameter conrmation required
18.0 ... 19.7 Incorrect parameter number
Temperature monitoring
26.0 ON-delay time running
26.1 Tripping delay time running (limit value ϑ1)
26.2 Tripping delay time running (limit value ϑ2)
27.0 Limiting value ϑ1 overshot/undershot
27.1 Limiting value ϑ2 overshot/undershot
27.2 Warning limit ϑ1 overshot/undershot
27.3 Warning limit ϑ2 overshot/undershot
27.4 Reserved
Temperature sensor 1
28.0 Temperature sensor 1 - Measuring range overshoot
28.1 Temperature sensor 1 - Wire break
28.2 Temperature sensor 1 - Short-circuit
28.3 Reserved
29.0 Temperature sensor 1 - Measured value is above the two limit values (monitoring for overshoot)
29.1 Temperature sensor 1 - Measured value is above the rst limit value (monitoring for overshoot)
29.2 Temperature sensor 1 - Measured value is within range of limit values
29.3 Temperature sensor 1 - Measured value is below the rst limit value for overshoot (monitoring for under‐
shoot)
29.4 Temperature sensor 1 - Measured value is below the two limit values (monitoring for undershoot)
Process data and data sets
16.5 Data set 92 - Diagnostics
3RS2 temperature monitoring relay
104 Equipment Manual, 02/2022, A5E42462552002A/RS-AB/002
