Description
Cable plugs for single cable connection and double cable connection with surge
arrester (interface type C)
7.6 Current and voltage transformers
Technical data The technical data of the current transformers and the voltage transformers is given in the
associated order documents.
Cable plug / surge arrester Connection combination Deep cable
compartment cover
1
Make Ser. no. Type Design
2
Arrangement
3
Mounting
depth
[mm]
Deeper by a
4
[mm]
Nexans
1
(K)430TB/G + 300SA
(K)480TB/G + 800SA
(K)484TB/G + 800SA
Screened K + Ü 290 –
2 (K)430TB/G + (K)300PB/G + 300SA Screened K + K + Ü 395 105
3
(K)480TB/G + (K)800PB/G + 800SA
(K)484TB/G + (K)804PB/G + 800SA
Screened K + K + Ü 400 250
Südkabel 4 SET (12 / 24) + MUT (13 / 23) Screened K + Ü 302 105
5 SEHDT 23.1 + MUT 23 Screened K + Ü 302 105
6 2x SET (12 / 24) + MUT (13/23) with
coupling unit KU 23.2/23
Screened K + K + Ü 476 250
7 2x SEHDT 23.1 + MUT 23 with coupling
unit KU 23.2/23
Screened K + K + Ü 476 250
8 SEHDT (13 / 23) + MUT 33 Screened K + Ü 540 250
nkt cables 9 CB 24-630 + CSA 24... Screened K + Ü 290 –
10 AB 24-630 + ASA 24... Insulated K + Ü 290 105
11 CB 36-630 (1250) + CSA... Screened K + Ü 290 –
TE Connectivity 12 RICS 5139 + RDA... Insulated K + Ü 275 –
13 RSTI-58xx + RSTI-CC-58SAxx Screened K + Ü 285 –
14 RSTI-58xx + RSTI-CC-68SAxx Screened K + Ü 292 –
15 RSTI-x9xx + RSTI-CC-58SAxx Screened K + Ü 295 –
16 RSTI-x9xx + RSTI-CC-68SAxx Screened K + Ü 302 105
3M Germany 17 2x 93-EE705-6/xxx + MUT 23 mit with
coupling unit KU 23.2
Screened K + K + Ü 476 250
1
Only for 310 mm and 430 mm wide panels.
2
Use of current transformers and current sensors in combination with insulated systems on request
3
K = Cable plug, Ü = Surge arrester
4
For drawing, see page 20, "Deep cable compartment cover (option)".
