Description
40/121 Revision 05 • INSTALLATION AND OPERATING INSTRUCTIONS • 8DJH • 500-8067.9
6…7.2 400 4 38.4 63 6…12 292 30 012 43.63 –
80 6…12 292 30 012 43.80 45DB120V80PTS2
80 6…12 442 30 102 43.80 –
63 3…7.2 292 30 099 13.63 –
63 6…12 292 30 012 13.63 –
63 6…12 442 30 102 13.63 –
100 6…12 292 – 45DB120V100PTS2
500 4 48 80 6…12 292 30 012 43.80 –
80 6…12 442 30 102 43.80 –
80 3…7.2 292 30 099 13.80 –
80 6…12 292 30 012 13.80 –
80 6…12 442 30 102 13.80 –
100 6…12 292 30 012 43,100 45DB120V100PTS2
100 6…12 442 30 102 43,100 45DB120V100PTS3
630 4 61 100 6…12 442 30 102 43,100 –
125 6…12 292 30 103 43,125 45DB120V125PTS2
125 6…12 442 30 020 43,125 –
800 4 77 160 6…12 442 – 45DB120V160PTS3
10…12 20 4 1.15 4 6…12 292 30 004 13.4 –
50 4 2.9 10 6…12 292 30 004 13.10 45DB120V10PTD
10 6…12 442 30 101 13.10 –
10 10…17.5 292 30 255 13.10 –
10 10…17.5 442 30 231 13.10 –
10 10…24 442 30 006 13.10 45DB240V10PTD
75 4 4.3 10 6…12 292 30 004 13.10 45DB120V10PTD
10 6…12 442 30 101 13.10 –
10 10…17.5 292 30 255 13.10 –
10 10…17.5 442 30 231 13.10 –
10 10…24 442 30 006 13.10 45DB240V10PTD
100 4 5.8 16 6…12 292 30 004 13.16 –
16 6…12 442 30 101 13.16 –
16 10…17.5 292 30 255 13.16 –
16 10…17.5 442 30 231 13.16 –
16 10…24 442 30 006 13.16 45DB240V16PTD
125 4 7.2 16 6…12 292 30 004 13.16 45DB120V16PTD
16 6…12 442 30 101 13.16 –
16 10…17.5 292 30 255 13.16 –
16 10…17.5 442 30 231 13.16 –
16 10…24 442 30 006 13.16 45DB240V16PTD
20 10…24 442 – 45DB240V20PTD
160 4 9.3 20 6…12 292 30 004 13.20 45DB120V20PTD
20 6…12 442 30 101 13.20 –
20 10…17.5 292 30 221 13.20 –
20 10…17.5 442 30 231 13.20 –
20 10…24 442 30 006 13.20 45DB240V20PTD
200 4 11.5 25 6…12 292 30 004 13.25 45DB120V25PTD
25 6…12 442 30 101 13.25 –
25 10…17.5 292 30 221 13.25 –
25 10…17.5 442 30 231 13.25 –
25 10…24 442 30 006 13.25 45DB240V25PTD
250 4 14.5 25 6…12 292 30 004 13.25 45DB120V25PTD
25 6…12 442 30 101 13.25 –
25 10…17.5 292 30 221 13.25 –
25 10…17.5 442 30 231 13.25 –
25 10…24 442 30 006 13.25 45DB240V25PTD
31.5 6…12 292 30 004 13.31,5 –
31.5 6…12 442 30 101 13.31,5 –
31.5 10…17.5 292 30 221 13.31,5 –
System operating
voltage
Transformer HV HRC fuse-link Order number for HV HRC fuse-link
U
n
[kV] S
r
[kVA] u
K
[%] I
r
[A] I
r
[A] U
r
[kV] e [mm] Make SIBA Make Mersen
