Siemens 8DJH - Page 41

500-8067.9 • INSTALLATION AND OPERATING INSTRUCTIONS • 8DJH • Revision 05 41/121
Description
10…12 250 4 14.5 31.5 10…17.5 442 30 231 13.31,5 –
31.5 10…24 442 30 006 13.31,5 45DB240V32PTD
315 4 18.3 31.5 6…12 292 30 004 13.31,5 45DB120V32PTD
31.5 6…12 442 30 101 13.31,5 –
31.5 10…17.5 292 30 221 13.31,5 –
31.5 10…17.5 442 30 231 13.31,5 –
31.5 10…24 442 30 006 13.31,5 45DB240V32PTD
40 6…12 292 30 004 13.40 –
40 6…12 442 30 101 13.40 –
40 10…17.5 292 30 221 13.40 –
40 10…17.5 442 30 231 13.40 –
40 10…24 442 30 006 13.40 45DB240V40PTD
400 4 23.1 40 6…12 292 30 004 13.40 45DB120V40PTD
40 6…12 442 30 101 13.40 –
40 10…17.5 292 30 221 13.40 –
40 10…17.5 442 30 231 13.40 –
40 10…24 442 30 006 13.40 45DB240V40PTD
50 6…12 292 30 004 13.50 –
50 6…12 442 30 101 13.50 –
50 10…17.5 292 30 221 13.50 –
50 10…17.5 442 30 232 13.50 –
50 10…24 442 30 014 13.50 45DB240V50PTS
500 4 29 50 6…12 292 30 004 13.50 45DB120V50PTD
50 6…12 442 30 101 13.50 –
50 10…17.5 292 30 221 13.50 –
50 10…17.5 442 30 232 13.50 –
50 10…24 442 30 014 13.50 45DB240V50PTD
63 6…12 292 30 012 43.63 45DB120V63PTS2
63 10…24 442 30 014 43.63 45DB240V63PTD
630 4 36.4 63 6…12 292 30 012 43.63 –
80 10…24 442 30 014 43.80 45DB240V80PTS
63 6…12 292 30 012 13.63 45DB120V63PTD
63 6…12 442 30 102 13.63 –
63 10…17.5 442 30 232 13.63 –
80 6…12 292 30 012 43.80 45DB120V80PTS2
80 6…12 442 30 102 43.80 –
800 5…6 46.2 63 6…12 292 30 012 13.63 –
80 6…12 292 30 012 43.80 45DB120V80PTS2
80 6…12 442 30 102 43.80 –
80 10…24 442 – 45DB240V80PTS
1000 5…6 58 100 6…12 292 – 45DB120V100PTS2
100 6…12 442 30 102 43,100 45DB120V100PTS3
100 10…24 442 – 45DB240V100PTS
1250 5…6 72.2 125 6…12 292 – 45DB120V125PTS2
125 6…12 442 30 103 43,125 45DB120V125PTS3
125 10…24 442 – 45DB240V125PTS
13.8 20 4 0.8 3.15 10…24 442 30 006 13.3,15 –
50 4 2.1 6.3 10…17.5 442 30 231 13.6,3 –
6.3 10…24 442 30 006 13.6,3 –
10 10…24 442 – 45DB240V10PTD
75 4 3.2 6.3 10…17.5 442 30 231 13.6,3 –
10 10…17.5 442 30 231 13.10 –
10 10…24 442 30 006 13.10 45DB240V10PTD
100 4 4.2 10 10…17.5 442 30 231 13.10 –
16 10…17.5 442 30 231 13.16 –
16 10…24 442 30 006 13.16 45DB240V16PTD
125 4 5.3 10 10…17.5 442 30 231 13.10 –
16 10…17.5 442 30 231 13.16 –
System operating
voltage
Transformer HV HRC fuse-link Order number for HV HRC fuse-link
U
n
[kV] S
r
[kVA] u
K
[%] I
r
[A] I
r
[A] U
r
[kV] e [mm] Make SIBA Make Mersen
