3 System Setup
3 - 16 Instructions for Use
Gel Warmer
(Available only on systems with a touch screen)
WARNING: To avoid electrical shock and damage to the control panel resulting from ingress of
liquid, place the gel bottle and gel warmer on the side of the ultrasound system closest to the
patient.
Caution: Do not attempt to repair or alter the gel warmer. Contact your local Siemens service
representative immediately if your gel warmer appears to be damaged or malfunctions in any
way.
See also: Refer to the cleaning and disinfecting procedures in Chapter 2 in this manual.
When the ultrasound system is powered on, the gel warmer continuously heats the bottle of gel
inserted into the gel warmer.
Example of the gel warmer, front view.
1 Temperature control
2 Power control
3 Cap for collecting gel spilled from the inverted gel bottle
Example of the gel warmer, back view.
1 Support
2 Tab
3 Label
4 Power cable connector
5 Cap
