Page #296 background image
Appendix A Technical Description
A - 38 Instructions for Use
Audio, Video, and Data Transmission Connections — Input and Output
Signals
Port
Location
Example of Connection
Signal
RJ-45
Inside the input/output
panel door
Ethernet (10BaseT/100BaseT/1000BaseT) Bi-directional
HDMI (J18) Input/output panel Video recorder (video and audio) Output
HDMI (J19)
Input/output panel
Video recorder (video and audio)
Input
USB-A (J4A,
J4B, J5A, J5B)
Input/output panel
Printer, video recorder (remote control),
eSieFusion electronics unit, SIE1 data
transmission, headset and camera for virtual
communication with a Siemens service
representative
Bi-directional
DVI (J9) Input/output panel External monitor (digital or analog) Output
BNC-type (J13) Input/output panel ECG trigger Output
USB-A
Control panel
USB storage device
Bi-directional
USB-A Front system panel Footswitch Bi-directional
ECG connector
(ECG)
Physio panel ECG leads Input
Phone jack
(Aux 1 ECG)
Physio panel ECG external DC input Input
