4 Examination Fundamentals
Instructions for Use 4 - 21
Settings
Transducer name
Exam
General  Image optimization preset for the active priority mode.
 During contrast agent imaging, indicates the balance of the image shown on the right
side of the screen:
– 2D displays only the 2D image
– CA displays only the image with the contrast agent
– MIX displays a combination of the 2D image and the image with contrast agent
DVR Track 1 0:00:08 (Displayed only when the DVR and media are ready for recording)
DVR track and time
Soft tissue thermal index
TIB: 0.4 (Displayed only for fetal applications)
Mechanical index
MIF: 0.02 (Displayed only when contrast agent imaging is activated)
Maximum of the mechanical indices measured at the active focal zones
Frame rate
2D-mode Settings
Example Parameter
Imaging mode / transmit power
THI Submode:
 THI indicates tissue harmonic imaging
 GEN indicates fundamental imaging
 Contrast indicates contrast agent imaging

indicates contrast agent imaging (for systems without a touch screen)
H5.50 MHz Transmit frequency
Note: The transmit frequency is preceded by an H (harmonic) or HC (harmonic
compounding) when THI is activated. The transmit frequency is preceded by CPS or CHI
during contrast agent imaging when contrast pulse sequence or contrast harmonic
imaging is activated. ADI indicates the agent detection imaging technique is enabled.
