Appendix A Technical Description
Instructions for Use A - 5
Transducer Technology and Design Attributes
 Multi-D array transducer technology
 fourSight 4D transducer technology
 Wideband MultiHertz multiple frequency transducer technology
 Hanafy Lens transducer technology
 Virtual Format Imaging feature allows linear displays in a trapezoidal format
 2.0 to 17.0 MHz imaging range capability
 Three array transducer ports
 One auxiliary continuous wave transducer port
 Parking port for transducer storage
 Transducer holder for all transducer designs and gel bottle storage
 Micro-pinless connectors
 Electronic transducer selection
 Lightweight, ergonomic transducer design with SuppleFlex cables
 Image depth (maximum)
Maximum Display Depth (cm)
4C1 30
6C1 HD 30
8C3 HD 30
7CF1 24
7CF2 24
EC9-4 14
MC9-4 14
9EVF4 16
9L4 14
14L5 8
14L5 SP 8
18L6 HD 8
4V1c 30
8V3 18
4P1 30
V5Ms 18
V7M 18
CW2 N/A
CW5 N/A
AcuNav 10F 18
