Appendix D On-screen Controls
D - 8 Instructions for U se
ASC Dual (Available only when Advanced SieClear is enabled)
Advanced SieClear Dual
Enables or disables the display of two real-time images originating from the same
acquisition in a side-by-side format. The right side displays the 2D image with
Advanced SieClear enabled and the left side displays the 2D image with
Advanced SieClear disabled.
Transmit Power Adjusts the transmit power during real-time imaging.
Note: For systems without a touch screen, this selection is assigned to TX POWER.
Frequency MultiHz
(In combined mode imaging, affects only the active priority mode)
Adjusts the transmit frequency of the active multi-frequency transducer.
Note: For systems without a touch screen, this selection is assigned to MULTIHZ.
DR Dynamic Range
(In combined mode imaging, affects only the active priority mode)
Adjusts the overall contrast resolution of an image, sweep, or spectrum.
Note: For systems without a touch screen, this selection is assigned to DYN R.
DVR
Displays a control on the touch screen for recording images during imaging when a
digital video recorder is connected and configured for use with the system.
SieScape SieScape
Displays selections to acquire two-dimensional ultrasound images with a composite,
extended field of view, using the SieScape Panoramic Imaging feature.
E Elasticity Imaging
Provides access to features used to detect the relative stiffness of tissue: eSie Touch
elasticity imaging, Virtual Touch Imaging (VTI), Virtual Touch IQ (VTIQ), and
Virtual Touch Quantification (VTQ).
EI Color Elasticity Imaging Color
Displays selections in color to detect the relative stiffness of tissue, using the eSie Touch
elasticity imaging feature.
eSie Touch eSie Touch
Displays selections to detect the relative stiffness of tissue, using the eSie Touch
elasticity imaging feature.
Note: For systems without a touch screen, the selection is assigned to a button:
To Next Page
