Appendix D On-screen Controls
Instructions for Use D - 25
Body Marker (Available only on systems without a touch screen)
Body Marker
Displays a body marker on the screen and activates body marker selection.
Note: The selection is assigned to a button:
Delete Body Marker Delete current Body Marker
Removes the currently displayed body marker from the screen.
Note: For systems without a touch screen, the selection is assigned to a button:
Transducer Marker Transducer Marker
Adds or removes a transducer marker for the currently displayed body marker.
Note: For systems without a touch screen, the selection is assigned to a button:
Repositions and anchors the body marker.
(Available only on systems without a touch screen)
Add Arrow
Changes the text cursor into an arrow for placement of an arrow on the image screen.
Delete Arrow Delete last Arrow
Deletes the current arrow.
Length Changes the length of the arrow and indicates the length in pixels.
Angle (Available only on systems with a touch screen)
Changes the direction of the arrow tip and indicates the angle of the direction.
Rotate (Available only on systems without a touch screen)
Changes the direction of the arrow tip and indicates the angle of the direction.
