Appendix D On-screen Controls
D - 34 Instructions for Use
Protocol Text (Available only for images captured during a workflow protocol)
Displays or hides the view name:
 On displays the view names on the review screen and the thumbnail panel.
 Off hides view names.
Sort Mode (Available only for images captured during a workflow protocol)
Sorts the protocol views by the selected criterion:
 Time displays images in the sequence they were captured.
 View displays images in the sequence that the views were displayed in the thumbnail panel
when the protocol was activated.
Note: Images captured before the protocol was activated are displayed before the sorted
protocol views. Images captured after the protocol was activated, including images captured
while the protocol was paused, are displayed after the sorted protocol views.
Use the system configuration menu to specify the sequence that views are displayed in the
thumbnail panel.
System Config > eSieScan Workflow Protocols
Compare Compare Mode
Displays only the selected images (static images, clips, or volumes) in the sequence the
images were selected.
# of #
Displays the number of images selected for comparison and the total number of images in the
study.
Remove image(s) Remove Image(s)
Hides the selected image from the displayed images currently selected for comparison.
Synchronization Synchronization
Selects the playback synchronization for the displayed clips:
 None or No Synchronization disables synchronization of clip playback.
 Sync Start begins playback for all clips at the same time. For example, begins playback for
a long and short clip at the same time. Does not begin playback again until the long clip has
completed playback.
 Sync Start/Stop begins and ends playback for all clips at the same time, adjusting speeds
for each clip, if necessary.
Cine Direction Reverses the direction of CINE playback.
