Appendix E Advanced Feature Controls
Instructions for Use E - 9
Plane (Available only when VOI is disabled)
Cut plane
Enables or disables the specified cut plane for the volume.
 Off
 1, 2
Maps (Applies only to MPRs)
Selects a processing curve that assigns echo amplitudes to gray levels.
 A, B, C, D, E, F, G, H, I, J, K, L
Note: The settings J, K, and L are available only for volumes acquired using contrast agent
imaging.
Reset All
Restores the default orientation and display format for all quadrants; also restores the default
(or user-defined) settings of other parameters for all quadrants. User-defined settings are those
that were in effect when the current volume was first displayed.
Reset Orientation Restores the default orientation for all quadrants.
Sync
Aligns the MPR and volume orientation. When the selected quadrant is an MPR, the system
aligns the orientation of the volume to that of the MPR.
Note: If the VOI is displayed when you select an MPR quadrant and then click Sync, the
system redefines the render direction to match the selected MPR.
Center On each slice, repositions the focal point to the center of the quadrant.
Reverses the render direction.
Bright Brightness
Adjusts the percentage of brightness in 2D-mode data included in the volume. An increase in
brightness increases the saturation of voxels that have a higher voxel value and increases the
brightness of voxels that have a lower voxel value.

to
Blend Blend Color
When enabled, combines (blends) 2D-mode and power data displayed within the volume
quadrant.
When disabled, superimposes (overlays) power data on the 2D-mode data displayed within the
volume quadrant.
 On
 Off
Activates or deactivates the trace editing tool.
