Set/reset operations
Operation Operand Function
S=
RB =
RD=
==
Set a formal operand (binary)
Reset a formal operand (binary)
Reset a formal operand (digital)
for timers and counters
Assign the value of the RLO to a
formal operand
Insert formal operand
Inputs, outputs and F flags addressed in binary
(parameter type: I, Q; data type BI) are permitted
as actual operands.
Operation Operand Function
SU
I 0.0 to 127.7
Q 0.0 to 127.7
F 0.0 to 255.7
D 0.0 to 255.15
T 0.0 to 255.15
C 0.0 to 255.15
RI 0.0 to 255.15
RJ 0.0 to 255.15
RS 60.0 to 63.15
RT 0.0 to 255.15
Unconditional setting
of an input (PII)
of an output (PIQ)
of a flag
of a data word bit
of a timer word bit
of a counter word bit
of a bit in RI area
of a bit in RJ area
of a bit in RS area
of a bit in RT area
RU
I 0.0 to 127.7
Q 0.0 to 127.7
F 0.0 to 255.7
D 0.0 to 255.15
T 0.0 to 255.15
C 0.0 to 255.15
RI 0.0 to 255.15
RJ 0.0 to 255.15
RS 60.0 to 63.15
RT 0.0 to 255.15
Unconditional resetting
of an input (PII)
of an output (PIQ)
of a flag
of a data word bit
of a timer word bit
of a counter word bit
of a bit in RI area
of a bit in RJ area
of a bit in RS area
of a bit in RT area
Table 3-14 Set/reset operations with formal operands
Table 3-15 Set and reset operations
Supplementary Operations
CPU 948 Programming Guide
3 - 52 C79000-G8576-C848-04
