9.3 Transferring Memory Blocks
Application
With the operations explained in this section, you can re-store data
areas with a length of up to 255 words located in certain address areas.
Operations
Operation Operand Function
TNW 0 to 255 Field transfer 0 to 255 words
1)
(in the 16-bit memory area)
TXB -- Field transfer from 8-bit to the 16-bit
memory
TXW -- Field transfer from the 16-bit to the
8-bit memory
1)
Can also be used for transfer from the byte to the byte area.
Parameters
Field length
For TNW: Operand = number of words (0 to 255)
For TXB/TXW ACCU 3 = number of words (0 to 127)
End address of the source area
ACCU 2 = end address of the source area (20 bits)
End address of the destination area
ACCU 1 = end address of the destination area (20 bits)
The entire source and destination areas must be located in one of the
memory areas listed in Table 9-5 and cannot overlap.
Permitted memory areas
Addresses Memory area
0 0000H to C FFFFH
User memory:
16-bit area (dependent on memory
configuration)
Table 9-4 Operations for field transfer
Table 9-5 Memory areas permitted for TNW, TXB and TXW
Transferring Memory Blocks
CPU 948 Programming Guide
C79000-G8576-C848-04
9 - 19
