Siemens CPU 948 - Bit Assignment of the System Data Words

8.3.5
Bit Assignment of the
System Data Words
System data RS 0 Input byte IB 0 Image table (external process interrupts)
Address E F000H
High byte
Bit no. Assignment
15
Occupied by system program
14
13
12
11
10
9
8
Low byte
7 Status of I 0.7
6 Status of I 0.6
5 Status of I 0.5
4 Status of I 0.4
3 Status of I 0.3
2 Status of I 0.2
1 Status of I 0.1
0 Status of I 0.0
Table 8-3 Bits in RS 0 (image of IB 0)
Bit Assignment of the System Data Words
