The following situations are possible:
•• DB is longer than source area:
If the data block is sufficiently long, you obtain a 32-word long
area per field as shown in the table above.
•• DB is too short:
If the end of the data block is within the selected field, in the last
field an area with a length between 1 and 32 words will be
transferred.
•• Field is outside the DB:
If the first data word address of a field is not within the length of
the data block, the SEND function detects and indicates an error.
Example
10.5.4
Output Parameters
Condition code byte This byte informs you whether the SEND function was executed
correctly and completely.
Initialization conflict Has no significance with the SEND function.
Data block with a length of 80 words: DW 0 to
DW 74, 5 words are required for the block header.
Field no.: First data word: Last data word: Length:
0 DW 0 DW 31 32 words
1 DW 32 DW 63 32 words
2 DW 64 DW 74 11 words
3 and
higher Incorrect parameter assignment
SEND Function (OB 202)
CPU 948 Programming Guide
10 - 42 C79000-G8576-C848-04
