Siemens CPU 948 User Manual

Bit no.:
Address:
E F000H
E F200H
E F400H
E F600H
E F800H
E FA00H
E FC00H
E FD00H
E FE00H
E FE80H
E FF00H
E FFFFH
Reserved
Reserved
Reserved
Reserved
Reserved
Reserved
Reserved
Reserved
PII
PIQ
Flags
Counters (256)
Timers (256)
RT Area (Extended System Data, 256 Words)
RJ Area (Extended Serial Comm. Interface, 256 Words)
RI Area (Serial Comm. Interface, 256 Words)
RS Area (System Data, 256 Words)
15
8
7
0
Fig. 8-3 Memory assignment of the system RAM/Part 2
Memory Assignment in the CPU 948
CPU 948 Programming Guide
C79000-G8576-C848-04
8 - 7
