Note
The following examples of applications involve finished applications
that you can program by copying them.
Programming function
blocks
FB 200: initializing the links
FB 200
INITIAL
(1) AUMA INIC (5)
(2) NUMC TCAP (6)
(3) TNAS
(4) STAS
Parameter
name
Significance Parameter
type
Data
type
Parameter
field
AUMA
NUMC
TNAS
STAS
INIC
TCAP
Automatic/manual
Number of CPUs
Type (H byte) and number (L byte)
of the data block containing the
assignment list
Start address of the assignment list
Initialization conflict
Total capacity
I
I
I
I
Q
Q
BY
BY
W
W
BY
BY
FY 246
FY 247
FW 248
FW 250
FY 252
FY 253
Continued on the next page
Applications
CPU 948 Programming Guide
10 - 54 C79000-G8576-C848-04
