"Floating point root extractor" continued:
STL method of representation LAD method of representation
Seg- : C DB 17
ment : SEGMENT 2
1:***
: JU FB 6 FB 6
Seg- NAME : RAD : GP RAD
ment RADI : DD 5 DD 5 RADI VZ F 15.0
2 VZ : F 15.0 SQRT DD 10
*) SQRT : DD 10 :BE
DD= data double word
*) Must be located in separate segments, since the operation "C DB 17" in
segment 1 cannot be converted to LAD/CSF.
Function Blocks
CPU 948 Programming Guide
2 - 34 C79000-G8576-C848-04
