Programming Manual of FC2005/FC901
A6V10333724_b_en_-- 17|63
3. HOW TO DISABLE/ENABLE
Function: This feature allows devices to be disabled for service. A trouble condition is annunciated whenever
the disable feature is used and cleared when enabled.
Note: Disabled device cannot send any message to controller.
Steps to disable (i.e., disable a NAC device):
1. Select a device by navigating hardware tree (Fig. 6-1).
2. Press “Menu” to display the main menu (Fig. 6-2).
3. Press “→” to select “Oper” submenu (Fig. 6-3). Press “↓” to
select “Disable” and then press “OK”. A warning screen is
displayed (Fig. 6-4).
4. Press “OK” to disable the device.
Steps to enable:
Same as the steps to disable. The only difference is to select
“Enable” instead of “Disable” in step 3.
Fig.6-1
Fig.6-2
Fig.6-3
Fig.6-4
